Funding
Materiales fotónicos para mejorar el proceso de afterglow en láminas delgadas transparentes con luminiscencia persistente
Ministerio de Ciencia e Innovación. “Europa Excelencia”. EUR2023-143467
Dec. 2023 – Nov. 2025
Persistent luminescent (PersL) materials are able to store optical energy in structural defects that act as traps and generate light long after the excitation source disappears, i.e. afterglow, allowing the introduction of time as a design element in new lighting solutions. Despite the advantages associated with size reduction, the properties of persistent nanomaterials are far from those of their bulk counterparts. PHLOW seeks to find new ways to control PersL by designing the optical environment of emitters, a path unexplored until today. To this end, it is proposed to process transparent thin films with PersL for integration into photonic architectures in order to optimize the charging process and improve the amount of light emitted during the afterglow. It is relevant to note that the charge storage and emission processes compete with each other. That is, as the traps are filled, they are also partially emptied in a dynamic process. However, there is no strategy specifically designed to alter the charging process or increase the population of the traps. At the same time, the radiative de-excitation rate of a transition depends on the optical environment through the local density of optical states. For this reason, the optical design is expected to have an impact, in addition to the outcoupling mechanism, on the intrinsic process of light generation, which should allow altering the trap population balance, affecting the charge kinetics and the intensity of the PersL. Thus, the general objective is to study the impact of changes in the optical environment on the processes of energy storage and persistent light emission in order to highlight the potential of optical design as a tool to control PersL in transparent thin films. This naturally interdisciplinary approach will have a profound scientific impact, as photonics has never been explored to control the charge and emission mechanisms that determine PersL, but also technological, as it enables the development of timedependent light sources to drive more versatile color converters, smart labels, novel coatings for anti-counterfeiting or optical data storage.
INFLUENCE OF THE OPTICAL ENVIRONMENT ON PERSISTENT LUMINESCENCE NANOMATERIALS: A NEW TOOL FOR THE DESIGN OF NANOBATTERIES OF LIGHT
Entidad financiadora: Beca Leonardo a Investigadores y Creadores Culturales. Fundación BBVA.
May 2023 – Nov. 2024
The development of societies is linked to their ability to generate artificial light, from torches to today’s ubiquitous light-emitting diodes (LEDs). Persistent luminescence (PersL) materials are able to store optical energy in structural defects and generate light long after the excitation source disappears, making them batteries of light. Despite the advantages associated with size reduction, the properties of persistent nanomaterials are far from those of their bulk counterparts used in signaling or ornamentation. This proposal pursues to integrate PersL nanomaterials into transparent thin films and to precisely characterize the charging kinetics and the amount of light emitted during afterglow as a function of the optical environment of the coatings. Photonics has never been explored to control the charging and emission mechanisms that determine PersL, which may have an impact on the development of more versatile color converters, smart labels, anti-counterfeiting elements or optical data storage.
PHOTOSINT. PHOTOelectrocatalytic systems for Solar fuels energy INTegration into the industry with local resources
Call: HORIZON-CL5-2022-D3-02. Topic: HORIZON-CL5-2022-D3-02-06. Type of action: HORIZON Research and Innovation Actions
Sep. 2023 – Aug. 2027
The PHOTOSINT project presents solutions to the challenges chemical industries are facing in integrating renewable energy sources into their processes. The project will deliver sustainable processes to produce hydrogen and methanol as energy vectors using only sunlight as an energy source and wastewater and CO2 as feedstocks, making the industries more auto-sufficient. The pathway is based on solar-driven artificial photosynthesis, and aims to develop new catalytic earth-abundant materials and modifications of existing ones to improve catalytic processes. Design parameters of the PEC cell will be tuned to maximize solar to fuel (STF) efficiency. Moreover to improve the conversion for industrial implementation, PHOTOSINT will develop a novel way to concentrate and illuminate the semiconductor surface to maximize overall energy efficiency. Perovskite solar PV cells will be integrated to harvest the light to supply the external electrical voltage.
PHOTOSINT is an ambitious project due to precedents in research conducted to date and the low production rate of the desired products. For integrating sunlight energy into the industry, the catalyst will be studied, and then the best one/s will be implemented in prototypes. The obtained results will be used for making scale-up in pilots with tandem PEC cells. These steps are necessary to assess the industrial scale-up feasibility, promoting the increased competitiveness of renewable process energy technologies and energy independence. MeOH and H2 will be tested in engines. Also, an HTPEM fuel cell will be used for electricity generation, and hydrogen will be tested as an alternative fuel for energy generation instead natural gas in melting furnaces avoiding CO2 emissions.
ESPER2- Photophysical Analysis of Parameters Affecting Efficiency and Stability of Dry Processed Metal Halide Perovskite Solar Cells: Activation and Degradation Processes
Ministerio de Ciencia e Innovación (Nº expediente: TED2021-129679B-C22 ).
Dic. 2022 – Nov. 2024
Advanced photophysical characterization has proven to be a key tool in the study of the optoelectronic properties of metal halide perovskites. Over the past decade time-resolved absoprtion and emission measurements have unveiled the unique photophysics of this material and have contributed to explain both, their outstanding performance in light harvesting and emitting devices but also its main limitations, such as material instability. These measurements have thus been used as a means to guide materials fabrication beyond trial and error approaches and have contributed to turning perovskites into the fastest growing photovoltaic technology. In this regard, advanced optical characterization will be employed in the present subproject (ESPER2) to bring vacuum thermal evaporated PV devices one step closer to the optimal performance in terms of efficiency as well as stability. A combination of steady state and time-resolved optical characterization experiments will be performed on perovskite films, architectures and devices in order to understand those factors affecting its performance: the presence of crystalline defects (and means to avoid them via compositional changes and passivating agents), the transfer of charges from the perovksite to adjacent charge transporting layers and the presence of photo-induced processes (such as photo activation and degradation) as well as the possibility of using the latter as a means to improve the materials optoelectronic properties. Beyond extracting critical information regarding charge recombination and transport, an optical design will be carried out in order to optimize light harvesting within the device comprising the best performing materials. The proposed characterization will thus help bringing a technology amenable to be used for mass production, such as vacuum deposition, closer to the market demands in terms of efficiency and durability.
FreeDot- Optimized Photonic Design of Ligand-Free Perovskite Quantum Dot based Optoelectronic Devices
Ministerio de Ciencia e Innovación (Nº expediente: PID2020-116593RB-I00).
Sep. 2021 – Aug. 2024
The motivation of the FreeDot project is three-fold. First, to propose solutions to the specific drawbacks hindering further development of perovskite optoelectronic technology (instability, durability, environmental sensitivity, etc.) by developing nanostructured solar cells and LEDs based on novel porous scaffolds that permit the synthesis of ligand-free nanocrystal assemblies, which show dot-to-dot charge transport while, simultaneously, minimizing their exposure to degrading environments. Second, to prove that improved power conversion efficiency, in the case of solar cells, and enhanced outcoupling and control over the spectral and directional properties of the emitted light, in the case of LEDs, are achievable through the optimization of the optical design also for quantum dot based devices. Finally, the synthesis of ligand-free nanocrystals opens the possibility to study fundamental photophysical properties of quantum dots, which are hindered by the presence of organic cappings in colloidal nanocrystals.
PERSEPHONe – PERovskite SEmiconductors for PHOtoNics
Research Executive Agency – European Union.
Mar. 2021 – Feb. 2025
Funded by the Marie Skłodowska-Curie programme, PERSEPHONe is a coordinated training network that aims to equip young researchers with new skills and knowledge regarding the development of a novel photonics technological platform based on metal-halide perovskite semiconductors. These materials present unrivalled optoelectronic properties and can be engineered to achieve a large set of desirable functionalities which may change the roadmap of currently established photonic technologies. They also show great promise for their integration with silicon photonics and silicon-oxynitride-based photonics. The programme will expose 14 early-stage researchers to a wide spectrum of research activities including material synthesis, photonic (and optoelectronic) device and integrated circuit fabrication, characterisation, modelling, upscaling and manufacturing. PERSEPHONe will lay the foundation for a novel photonic technology, strengthening Europe’s position in the field.
DESARROLLO DE DISPOSITIVOS EMISORES DE LUZ BASADOS EN PEROVSKITA NANOESTRUCTURADA
Junta de Andalucía. (Nº de expediente: P18-RT-2291)
Jan. 2020 – Dic. 2022
The Nano-ABX LED project proposes the preparation, characterization and integration into light-emitting devices of perovskite nanocrystals synthesized inside porous matrices, mainly using scalable solution processing techniques compatible with those usually used to manufacture the devices object of study.
RESULTS
The main advance in knowledge and technology in the field of optoelectronic materials and devices carried out within the framework of the Nano-ABX LED project is the development of an innovative device configuration, different from those based on massive thin sheets (bulk) or stacks of colloidal nanocrystals, the only two used so far in the field of perovskite-based emission. The results obtained demonstrate the feasibility and great potential of this approach. As an example, it has allowed us to prepare emitting nanocrystals in the blue range of the electromagnetic spectrum with a quantum efficiency not yet achieved.
The objectives proposed within the Nano-ABX LED project fit within the Social Challenge called “Safe, clean and efficient energy” identified within the Andalusian Innovation Strategy 2020 (RIS-3) and the Andalusian Plan for Research, Development and Innovation (PAIDI 2020). Specifically, the results obtained, which demonstrate an alternative and low-cost way to obtain highly efficient emitters, will contribute to the Andalusian Energy Strategy 2020, which aims to achieve a more efficient, decarbonised, intelligent and quality energy system, in line with one of the five main development areas contemplated in the Europe 2020 strategy (http://ec.europa.eu/europe2020/). which establishes as one of its main objectives to increase energy efficiency in Europe by 20%, to which the development of the light-emitting devices obtained within the framework of the project would contribute.
ENERGÍA SOLAR Y NANOCIENCIA. KIT DEMOSTRATIVO (http://nanosolarkit.icms.us-csic.es/)
Fundación General CSIC. (FGCC‐2020‐0004)
Ene. – Sept. 2021
This project pursues the dissemination of the use of nanotechnology in the field of renewable energies. For this purpose, we developed a demonstrative kit based on dye solar cells where the dye is extracted from berry fruits. The project will be in charge to fabricate and to spread the kit to the general public in the framework of dissemination activities.
VERSUS – VERIFICATION OF THE EXISTENCE OF MACROSCALE REPULSIVE CASIMIR FORCES IN SUSPENDED SELF-STANDING FILMS
Ministerio de Ciencia, Innovación y Universidades (Nº expediente: FIS2017-91018-EXP).
Nov. 2018 – Oct. 2020
The ultimate goal of the VERSUS project is the first observation of repulsive Casimir-Lifshitz forces in macroscopic plane-parallel systems. To this end, it will focus on the design, fabrication, and characterization of optical materials that allow controlling the intensity and nature of the Casimir-Lifshitz force, so that levitation phenomena can be observed and characterized due to the balance between the latter and gravity force.
MODO – MATERIALES ÓPTICOS AVANZADOS PARA DISPOSITIVOS OPTOELECTRÓNICOS MÁS EFICIENTES
Ministerio de Ciencia, Innovación y Universidades (Nº expediente: MAT2017-88584-R).
Ene. 2018 – Dec. 2020
The MODO project is focused on the optimization of the optical design of optoelectronic devices, be they photovoltaic or light emitting ones, with the aim of increasing their efficiency or endow them with new functionalities. The hypothesis on which it is based is that this goal can be reached by means of the integration of optical materials that allow controlling the radiation-matter interaction in the absorbing or optically active layers of the device.
NANOPHOM – NANOPHOSPHOR-BASED PHOTONIC MATERIALS FOR NEXT GENERATION LIGHT-EMITTING DEVICES
European Research Council Executive Agency
Apr. 2017 – Mar. 2022
Energy-efficient and environmentally friendly light sources are an essential part of the global strategy to reduce the worldwide electricity consumption. Light-emitting diodes (LEDs) emerge as a key alternative to conventional lighting, due to their high power-conversion efficiency, long lifetime, fast switching, robustness, and compact size. Nonetheless, their implementation in the consumer electronic industry is hampered by the limited control over brightness, colour quality and directionality of LED emission that conventional optical elements relying on geometrical optics provide. NANOPHOM seeks to explore new ways of controlling the emission characteristics of nanophosphors, surpassing the limits imposed by conventional optics, through the use of nanophotonics. The development of reliable and scalable nanophosphor-based photonic materials will allow ultimate spectral and angular control over the light emission properties, addressing the critical shortcomings of current LEDs. The new optical design of these devices will be based on multilayers, surface textures and nano-scatterers of controlled composition, size and shape, to attain large-area materials possessing photonic properties that will enable a precise management of the visible radiation.
POLIGHT – POLYMER-INORGANIC FLEXIBLE NANOSTRUCTURED FILMS FOR THE CONTROL OF LIGHT
European Research Council Executive Agency
Dec. 2012 – Nov. 2017
The POLIGHT project focuses on the integration of a series of inorganic nanostructured materials possessing photonic or combined photonic and plasmonic properties into polymeric films, providing a significant advance with respect to current state of the art in flexible photonics. These highly adaptable films could act either as passive UV-Vis-NIR selective frequency mirrors or filters, or as matrices for light absorbing or optically active species capable of tailoring their optical response. The goal of this project is two-fold. In one aspect, the aim is to fill a currently existing hole in the field of materials for radiation protection, which is the absence of highly flexible and adaptable films in which selected ranges of the electromagnetic spectrum wavelengths can be sharply blocked or allowed to pass depending on the different foreseen applications. In another, the POLIGHT project seeks to go one step beyond in the integration of absorbing and emitting nanomaterials into simple flexible polymeric matrices by including hierarchically structured photonic lattices that provide fine tuning of the optical properties of these hybrid ensembles. This will be achieved by means of enhanced matter-radiation interactions that result from field localization effects at specific resonant modes. The opportunity arises as a result of the recent development of a series of robust inorganic photonic structures that present interconnected porous networks susceptible of hosting polymers and thus inheriting their mechanical properties.
MODO – MATERIALES ÓPTICOS AVANZADOS PARA DISPOSITIVOS OPTOELECTRÓNICOS MÁS EFICIENTES
Ministerio de Economía y Competitividad (Nº expediente: MAT2014-54852-R).
Ene. 2015 – Dec. 2017
The MODO project will focus on the development of optical materials to optimize the performance of optoelectronic devices such as solar cells or light emitting devices, thereby improving their energy conversion efficiency. The main objective of this proposal is to increase their performance by controlling light absorption and emission processes occurring in the materials composing these devices. This will be achieved through the design and integration of photonic nanostructures whose properties are also compatible with the manufacture and operation requirements of these systems, such as thermal, chemical and mechanical stability, durability, ease of processing and scale-up.
HOUSESS – HIGHLY OPTIMIZED UNIT FOR SUSTAINABLE ENHANCED SOLAR SYSTEM
Ministerio de Economía y Competitividad (Nº expediente: RTC-2014-2333-3).
Feb. 2014 – Dec. 2017
Abengoa Solar New Technologies coordinará el proyecto denominado “Housess -Highly Optimized Unit for a Sustainable Enhanced Solar System”. El proyecto se centra en el desarrollo de un sistema híbrido fotovoltaico térmico para grandes plantas de producción, caracterizado por una mayor eficiencia, menores costes que la tecnología estándar termosolar y gestionabilidad de la electricidad generada. El proyecto ha sido subvencionado dentro de la Programa estatal de I+D+i orientado a los Retos de la Sociedad del Ministerio de Economía y Competitividad, con número de expediente RTC-2014-2333-3. El consorcio del proyecto Housess está constituido por las siguientes empresas, universidades y centros de investigación: Abengoa Solar New Technologies, Universidad Politécnica de Madrid, Instituto de Ciencia de Materiales de Sevilla (CSIC) e Instituto de Ciencia de Materiales de Madrid (CSIC).
PhoLED – Photonic nanostructures for Light-Emitting Devices
Research Executive Agency – European Union.
Sep. 2015 – Aug. 2017
This project has received funding from the European Union’s H2020 Programme for research, technological development and demonstration under grant agreement no 657434.
The PhoLED project seeks to largely surpass the optical performance of state-of-the-art light emitters devised for illumination applications and contribute to solve some of the main technical limitations that the current technology presents. This project aims at integrating novel optical nanostructures and emitters, such as colloidal quantum dots or nanophosphors, to yield the next generation of light-emitting devices in which full spectral and angular control over the emission properties will be possible. The approach focuses on the development of: i) new synthetic routes to achieve efficient nanophosphors, and ii) preparation and processing strategies, based on surface textures and colloidal scatterers, to attain large area optical nanostructures possessing photonic properties that will allow a precise control on the intensity, angular distribution and color quality of light emission. Results achieved within this project will provide significant advance both in the comprehension of fundamental phenomena as well as in the development of versatile solid-state lighting devices of optimized efficiency, aiming to overcome technical barriers and maximize performance. The project’s outcome is twofold: a substantial expansion of the preparation of optical nanostructures to control light-mater interaction, and the practical realization of nanostructured lightemitting devices with unprecedented properties.
INPHOFLEX – Integration Of Photonic Nanostructures In Flexible Dye Solar Cells
Research Executive Agency – European Union.
Sep. 2014 – Aug. 2016
This project has received funding from the European Union’s Seventh Framework Programme for research, technological development and demonstration under grant agreement no 622533.
It is the main goal of this project to bring to the host institution and the European Research Area the knowledge and technology to prepare current record flexible dye sensitized photovoltaic devices, previously developed by the candidate in South Korea and then the USA, in order to be able to further improve them, while endowing them with semi-transparency, using stretchable and bendable optical materials. The candidate has demonstrated that several key materials and processes provide better performance of bendable dye solar cells, i.e., enhanced efficiency and flexibility, by allowing the preparation of electrodes in which the electron diffusion length is longer and charge collection efficiency is consequently enhanced. However, highly efficient dye solar cells are opaque as a consequence of the particular diffuse scattering design employed to improve light absorption, which limits their application in building or automotive integrated photovoltaics. This proposal seeks to solve such drawback by introducing photonic nanostructures in different configurations, yielding both light harvesting enhancement and preserving transparency, hence placing Europe at the forefront of research in this specific area within the field of renewable energy. This final goal will be attempted through different approaches, each one challenging from the materials science perspective. Preparation of such highly efficient and transparent devices will combine the flexible solar cell processing tools previously developed by the candidate with the versatile optical material preparation techniques pioneered by the host institution. More specifically, integration of novel porous flexible photonic structures into the light harvesting layer, use of flexible mirrors attached to the back of the counter-electrode, and designed distribution of scatterers will be employed to reach the target.
CONTROL DE LA ABSORCION Y LA EMISION OPTICAS DE NANOMATERIALES INTEGRADOS EN ESTRUCTURAS FOTONICAS POROSAS MULTIFUNCIONALES
Ministerio de Ciencia e Innovación
Jan. 2012 – Dec. 2014
In this project the modifications of both optical emission and absorption of nanomaterials of different sort (rare earth doped nanoparticles, semiconductor quantum dots, metallic nanoparticles, and films of organic dyes of nanometer dimensions) that occur when they are embedded in different types of photonic structures are being investigated. Both fundamental and applied aspects of the subject are analysed. Efforts are mainly focused on materials of current technological interest for solar cells, sensors and light emitting devices. From the applied point of view, this project finds its motivation in the possibility that photonic structures offer of modifying absorption and emission processes in a controlled manner so that they can be inhibited or amplified depending on the specific goal pursued. Particularly, we seek to put into practice these concepts to generate new designs of more efficient solar cells, capable of harvesting a larger amount of the incident radiation, and in the development of films for sensing devices responsive to modifications of different kind, such as presence of targeted molecules, variations of ambient gas pressure, etc… Also, more efficient or controlled light extraction from light emitting devices is sought after. The development of small prototype devices to prove the novel concepts under research is also an objective of this grant proposal.
In its more fundamental aspect, our project aims at deepening our knowledge of the interaction between light and matter in systems in which there exists a strong dispersion and anisotropy of the dielectric constant, and in which it is possible to attain very low photon propagation speeds. For this analysis, different types of porous photonic structures are being employed, such as one-dimensional and three-dimensional photonic crystals, as well as disordered assemblies of particles, as hosts in which a wide range of organic and inorganic nanomaterials are being integrated in different configurations and whose absorption and emission are being experimentally and theoretically studied. Although this project has a fundamental character due to the nature of the preparation techniques and complex optical properties we seek to analyze, it is our aim to continue generating and transferring intellectual property based on the novel concepts, properties and designs which are the subject of our research.
NANOESTRUCTURAS HÍBRIDAS FLEXIBLES PARA SU APLICACIÓN COMO FILTROS DE RADIACIÓN ULTRAVIOLETA, VISIBLE E INFRARROJA
Junta de Andalucía.
Jan. 2010 – Jan. 2013
The project objective is the development of flexible interference filters reflecting selected ranges of ultraviolet (UV), visible (Vis) and infrared (IR) radiation. In addition, they are transferable and adhesive, allowing their adaptation to different types of surfaces. An immediate application of these new dielectric mirrors is their use as adhesive and transparent skin protectors against high energy solar radiation (mainly known as the UVA range, wavelengths from 315 nm to 400 nm). Therefore emphasis has been placed on integration of polymers compatible with human skin.
HYBRID OPTOELECTRONIC AND PHOTOVOLTAIC DEVICES FOR RENEWABLE ENERGY
Ministerio de Ciencia e Innovación
Dec. 2008 – Dec. 2012
Nanostructured metal-oxides, and organic conductors with luminescent properties, allow to realize a range of photovoltaic and electrooptical devices that will contribute significantly to the production of carbon-free energy as well as to its efficient utilization in general lighting. This national project unites chemists, physical chemists, and physicists, with experience in organic and inorganic synthesis, semiconductors synthesis and processing, fundamental materials characterization, and the fabrication and characterization of devices, in order to realize a number of modern electrooptical devices such as molecular solar cells and organic light-emitting diodes (OLEDs). The main scientific elements of the project are: the preparation of substrates, the formation of semiconductor metal oxide nanostructures, the synthesis of molecular elements of functionalization and polymer materials, the analysis of morphologies, the control of the organic conductors and the interfaces. As a major technical objective, the integration of these elements in complete devices at the lab scale will be pursued, including dye-sensitized solar cells (Grätzel cells), plastic solar cells, hybrid organic-inorganic LEDs, light-emitting electrochemical cells (LECs) and OLEDs integrated with other devices.
APLICACIONES DE CRISTALES FOTÓNICOS EN CÉLULAS SOLARES: AUMENTO DE LA EFICIENCIA DE CONVERSIÓN DE POTENCIA MEDIANTE LA AMPLIFICACIÓN DE LA ABSORCIÓN ÓPTICA
Junta de Andalucía.
Jan. 2009 – Jan. 2012
The objective of the project is to achieve substantial improvements in efficiency in a solar cell by implementing in it photonic crystals. More specifically, this project aims to study the effect of anomalous propagation of electromagnetic radiation that takes place in photonic materials on the efficiency and the performance of dye solar cells of different types. The manufacture of thin films of colloidal particles of different types of oxides (titanium oxide, tin oxide, zinc oxide, silicon oxide, etc.) has been performed. The particles have been disposed both in an ordered network (colloidal crystal) and randomly dispersed but being part of a superstructure that shows a greater length scale order (nanoparticle multilayer structures).
CONTROL DE LA ABSORCION Y LA EMISION OPTICAS DE NANOMATERIALES EN CRISTALES FOTONICOS
Ministerio de Ciencia e Innovación
2008 – 2011
In this project the modifications of both optical emission and absorption of nanomateriales of different sort (rare earth doped nanoparticles, semiconductor quantum dots, and films of organic dyes of nanometer dimensions) that occur when they are embedded in a photonic crystal structure. Both fundamental and applied aspects of the subject will be analysed, efforts being focused on materials of current technological interest. From the applied point of view, this project finds its motivation in the possibility that photonic crystal offer of modifying those absorption and emission processes in a controlled manner so that they can be inhibited or amplified depending on the specific goal pursued. Particularly, we seek to put into practice these concepts to generate new designs of more efficient solar cells, capable of harvesting a larger amount of the incident radiation, and in the development of films for sensing devices sensitive to modifcations of different kind, such as presence of targeted molecules, variations of ambient gas pressure, etc… In its more fundamental aspect, our project aims at deepening our knowledge of the interaction between light and matter in systems in which there exists a strong dispersion and anisotropy of the dielectric constant, and in which it is possible to attain very low photon propagation speeds. For this analysis, we will employ photonic crystals with three dimensional order as hosts in which a wide range of organic and inorganic nanomaterials will be integrated in different configurations and whose absorption and emission will be experimentally and theoretically studied.
FENÓMENOS DE ABSORCIÓN Y EMISIÓN ÓPTICAS EN CRISTALES FOTÓNICOS COLOIDALES
Ministerio de Ciencia e Innovación
2005 – 2008
The aim of this project is to study the modification of the optical absorption and emission of chromophores as a result of being part of a photonic crystal structure. This analysis will be done both from the applied and fundamental point of view, focusing on materials of interest for current optics or pigment industry. The main motivation of our research regarding its possible applications is the possibility to vary these optical phenomena in a controled manner, so they can be amplified or inhibited to will. In its fundamental aspects, our proposal seeks a deep understanding of the interaction between light and matter in which there exists a modulation of the dielectric constant and strong dispersity effects, and in which photons can travel at very low speeds. For this analysis, we will fabricate colloidal photonic crystals as matrices in which we will infiltrate the different organic and inorganic dyes or chromophores whose absorption and emission will be studied. Also, new photonic crystal structures in which these active compounds will be included as part of an optical dopant will be fabricated. The optical behaviour of these extrinsic photonic crystals will be analysed.
AMPLIFICACIÓN DE LA ABSORCIÓN ÓPTICA DE FOTONES LENTOS EN CRISTALES FOTONICOS: APLICACIONES A CELULAS SOLARES
2005 – 2007
Collaboration project with a research group belonging to the CONICET (Argentina) on synthesis of hierarchical titanium oxide, its implementation in solar cells and the theoretical modeling of their response. The improvement of the design of solar cells was achieved based on a better understanding of fundamental phenomena involved in the sought efficiency enhancement.
NUEVOS MATERIALES FOTOVOLTAICOS BASADOS EN ESTRUCURAS COLOIDALES
2004 – 2007
The main objective of this project was making new electrolyte semiconductor junction solar cells based on nanostructured coating made of materials such as TiO2, ZnO, Fe2O3, Nb2O5, WO3, and Ta2O5, aiming at an enhancement of the energy conversion efficiency due to anomalous phenomena of light propagation.
